FOR:Machinery Name: M/E NO.1 & NO.2 F.O CIRCULATING PUMP

Machinery Model/Type:  HHB-6MA

Specification: CAPACITY: 5.6M3/H, SUCTION PRESSURE: 4.0 BAR, DISCHARGE PRESSURE: 10.0 BAR, TOTAL PRESSURE: 6.0 BAR

Other details: MAKER: TAIKO KIKAI INDUSTRIES CO. LTD.

Drawing no.S0G06A1C3560

DRIVE SHAFTDRIVEN SHAFT

TAIKO KIKAI INDUSTRIES.HHB-6MA.102

DRIVE GEAR

TAIKO KIKAI INDUSTRIES.HHB-6MA.103

DRIVEN GEAR

TAIKO KIKAI INDUSTRIES.HHB-6MA.104

KEY

TAIKO KIKAI INDUSTRIES.HHB-6MA.105

BEARING NUT

TAIKO KIKAI INDUSTRIES.HHB-6MA.106

BEARING METTAL

TAIKO KIKAI INDUSTRIES.HHB-6MA.107

BALL BEARING

TAIKO KIKAI INDUSTRIES.HHB-6MA.150

COUPLING RING

TAIKO KIKAI INDUSTRIES.HHB-6MA.201/1

SPACER RING

TAIKO KIKAI INDUSTRIES.HHB-6MA.201/2

MECHANICAL SEAL

TAIKO KIKAI INDUSTRIES.HHB-6MA.202

O-RING

TAIKO KIKAI INDUSTRIES.HHB-6MA.304

OIL SEAL

TAIKO KIKAI INDUSTRIES.HHB-6MA.515

SAFETY VALVE

TAIKO KIKAI INDUSTRIES.HHB-6MA.520

SAFETY VALVE SEAT

TAIKO KIKAI INDUSTRIES.HHB-6MA.522

SAFETY VALVE SPRING

TAIKO KIKAI INDUSTRIES.HHB-6MA.530

TAIKO KIKAI INDUSTRIES.HHB-6MA.704

TAIKO KIKAI INDUSTRIES.HHB-6MA.706

TAIKO KIKAI INDUSTRIES.HHB-6MA.707

TAIKO KIKAI INDUSTRIES.HHB-6MA.714

TAIKO KIKAI INDUSTRIES.HHB-6MA.101
