"Actuator for Main Starting Valve of Main Engine. Starting valve type: Z0150S0817, 97971SHA.

ELECRO HYDROLIC SYSTEM - EHS - D3 VALVE ACTUATOR

EHS - D3 Double Acting Rotary Valve Actuator Specification

Type: EHS - D3 /34-0005

Ser. No.: 0804 - 8315" "EHS-D3 DOUBLE ACTING RETARY VALVE ACTUATOR;Motor Supply Voltage: 230V Ac

Start Current : 4 Amp

Nominal Current: 1.3 Amp

Frequency : 50/60 Hz

Power : Max. = 300W

Limit Switch or Signal Voltage: 24V Dc

Analog feed back Signal: 4 - 20 mA

Pressure: Max.= 150 Bar

pressure Sv1 = 110 Bar

Presure Sv2= 11Bar

Oil Capacity: 300 cm3

Temp. : Max. = 70oc

I.Duty: S3 - 10%

Protection Class: IP67

PT: 165 Bar

WP : 110 Bar

Valve No.: BAV8" NA.EHS-D3-34-0005.NA
