Please refer to INSTRUCTION MANUAL FOR PISTON COMPRESSOR CMO 24 CMO 26 CMO 28 TCMO 28 MK2

Johnson Controls

Air Cond. Compressor

Type: CMO 26

Refrigerant: R404A

Swept volume: 175

Year: 2010

Speed: 1800 rpm

Allowable pressure: LP side - max 21, test 32;

HP side - max 28, test 42.

GASKET FOR TOP COVER

NA.CMO26.2353-101-2B-1GASKET FOR SIDE COVER

NA.CMO26.2353-102-86B-1

SPRING

NA.CMO26.2142-059-21

GASKET FOR END COVER

NA.CMO26.2353-105-4B-1

GASKET 0.3MM

NA.CMO26.2353-166-5B-1

GASKET 0.5MM

NA.CMO26.2353-167-6B-1

O-RING

NA.CMO26.1331-050-7C-1

GASKET FOR DUST STRAINER

NA.CMO26.2353-118-7H-1

SHAFT SEAL COMPLETE

NA.CMO26.1331-017-9B-1

SEALING RING

NA.CMO26.3126-180

LOCKING RING

NA.CMO26.1331-075-11E-1

PISTON WITH PIN AND RINGS

NA.CMO26.2142-052-12F-1

MAIN BRARING BUSHING

NA.CMO26.1332-113-12G-1

MAIN BUSHING

NA.CMO26.1332-114-12H-1

CONNECTING ROD COMPLETE WITH BOLTS

NA.CMO26.3135-171-12J-1

SPRING FOR UNLOADING PIN

NA.CMO26.3124-062-18

RING PLATE FOR SUCTION VALVE

NA.CMO26.2132-086-5E-1

CYLINDER LINER COMPLETE-CMO AND TCMO LP-HFC FOR CAPACITY REGULATION

NA.CMO26.2132-086-6E-1

DISCHARGE VALVE COMPLETE HFC/HCFC

NA.CMO26.3123-077-17-1

RING PLATE FOR DISCHARGE VALVE

NA.CMO26.2142-034-19C-1

NA.CMO26.3131-072-19F-1

NA.CMO26.2356-288-19K-1

NA.CMO26.3112-076-19-4

NA.CMO26.3136-079-20-2

NA.CMO26.3131-006-20C-1
