ENGINE DESCRIPTION :FIRE DEDECTION AND FIRE ALARM SYSTEM

MAKER: NOHMI  BOSAI  LTD.

TYPE&ENG NO: TS1690 1691

INS. BOOK: F-35

DEDECTOR HEAD (IONIZATION TYPE FDS512B-J552B)

Fig. No. (DRW NO) 4961 2/2

NOHMI BOSAI LTD.TS1690.13THERMAL DETECTOR HEAD

(TYPE: FDL511-65/-75/-100)

Fig. No. (DRW NO) AJ-6953LS

NOHMI BOSAI LTD.TS1690.NA

PLEXI GLASS

TYPE:FMM 517/557

Fig. No. (DRW NO) 4961 2/2

NOHMI BOSAI LTD.TS1690.16

FLAME DETECTOR (NS-DIR) INFRARED TYPE RATING VOLTAGE 24V,DC VOLTAGE RANGE 10,30V,DC

Fig. No. (DRW NO) 4961 2/2

NOHMI BOSAI LTD.TS1690.15
