FOR FREEFALL LIFEBOAT

BUILDER JIANGSU JIAOYAN MARINE EQUIPMENT CO ., LTD.

TYPE JY-FN-5.8

BUILDING YEAR 2012

LOCATION:BOAT DECK

NUMBER OF PERSONS 24FOR DWG. NO.: FD5900-511300-0000

WITH ENGINE 1

FREE FALL DAVIT HYD. HOSE NO:101

HYD. DRAIN LINE , PF 3/8``, 12L-70KFREE FALL DAVIT HYD. HOSE NO:102

HYD. DRAIN LINE , PF 3/8`` , 12L-70K

JIANGSU JIAOYAN MARINE .JY-FN-5.80.102

FREE FALL DAVIT HYD. HOSE NO:201

HYD. PRESSURE LINE , PF 1/2`` , 16S-210K

JIANGSU JIAOYAN MARINE .JY-FN-5.80.201

FREE FALL DAVIT HYD. HOSE NO:202

HYD. PRESSURE LINE , PF 1/2`` , 16S-210K

JIANGSU JIAOYAN MARINE .JY-FN-5.80.202

FREE FALL DAVIT HYD. HOSE NO:203

HYD. PRESSURE LINE , PF 1/2`` , 16S-210K

JIANGSU JIAOYAN MARINE .JY-FN-5.80.203

FREE FALL DAVIT HYD. HOSE NO:204

HYD. PRESSURE LINE , PF 1/2`` , 16S-210K

JIANGSU JIAOYAN MARINE .JY-FN-5.80.204

FREE FALL DAVIT HYD. HOSE NO:205

HYD. PRESSURE LINE , PF 1/2`` , 16S-210K

JIANGSU JIAOYAN MARINE .JY-FN-5.80.205

FREE FALL DAVIT HYD. HOSE NO:301

HYD. RETURN LINE , PF 1/2`` , 16S-210K

JIANGSU JIAOYAN MARINE .JY-FN-5.80.301

FREE FALL DAVIT HYD. HOSE NO:302

HYD. RETURN LINE , PF 1/2`` , 16S-210K

JIANGSU JIAOYAN MARINE .JY-FN-5.80.302

FREE FALL DAVIT HYD. HOSE NO:303

HYD. RETURN LINE , PF 1/2`` , 16S-210K

JIANGSU JIAOYAN MARINE .JY-FN-5.80.303

FREE FALL DAVIT HYD. HOSE NO:304

HYD. RETURN LINE , PF 1/2`` , 16S-210K

JIANGSU JIAOYAN MARINE .JY-FN-5.80.304

FREE FALL DAVIT HYD. HOSE NO:305

HYD. RETURN LINE , PF 1/2`` , 16S-210K

JIANGSU JIAOYAN MARINE .JY-FN-5.80.305

FREE FALL DAVIT HYD. HOSE NO:306

HYD. RETURN LINE , PF 1/2`` , 16S-210K

JIANGSU JIAOYAN MARINE .JY-FN-5.80.306

JIANGSU JIAOYAN MARINE .JY-FN-5.80.206
