Test Certificate for Heat Exchanger

Technical Data: No. 1 Heat Exchanger

Type: P48AISPAC 2R 24T 2C L740 Pa6.1

Serial No: 05-56-4

Side/Medium: Tube / Oil

Max. allow working pressure: 10bar

Design Temp: 210 C

Heat trans. area: 22.4 meter squared

Materials: Tubes 16x1 : ASTM A213 TP316L Cert. 3.1.C GL 20619 GOA

Tubes 48.3 x 2.77 : ASTM A 312 TP316L Cert. 3.1.C GL 20619 GOA

Connection: 26.67 x 2.87 : ASTM A312 TP 316L Cert. 3.1.C GL 20619 GOA

HEAT EXCHANGER UNIT;Manufacturer: KLIMOR - Gdynia

Air Conditioning central unit type: KD5PI

Factory No: 29663

Execution: Right

Air Capacity: 8000m3/hr

Compression: 2500Pa

Type of the Heater: P48A ISPAC 2R 24T

Type of the pump: SKB2.02

Producer: 669065

Type of fan: WPBD-32/P2

Factory No.: 731513

KLIMOR.NA.NA
