MACH: HATCH COVER;

MODEL: SIDE ROLLING TYPE MECHANICS ;

MAKER: MaCCRECOR;

BOOK NO: HO(V)-1;

SPECIFICATION: HATCH COVER SIDE ROLLING INSTRUCTION MANUAL

DMHI MH.1057/58; PIPING OF ROLL UP ROLL CYLINDER; DWG. NO. 1355660WD-7150

MACCRECOR.SIDE ROLLING TYPE.NACOUPLING , WELDING SOCKET; TYPE:  K102034-10 , BSP 1/2"  x H/L15; ITEM NO: 8315

MACCRECOR.SIDE ROLLING TYPE.1071808

BEARING; ITEM NO: 2

MACCRECOR.SIDE ROLLING TYPE.1021849

SEALING RING; ITEM NO: 3

MACCRECOR.SIDE ROLLING TYPE.1018935

V-SEAL; ITEM NO: 4

MACCRECOR.SIDE ROLLING TYPE.1021850

O-RING; ITEM NO: 5

MACCRECOR.SIDE ROLLING TYPE.1004716

COUPLING, WELDING SOCKET; TYPE: K102032-30, BSP 1/2" x H25; ITEM NO: 8294

MACCRECOR.SIDE ROLLING TYPE.1022051

COUPLING, WELDING SOCKET; TYPE: K102032-10, BSP 1/2" x H15; ITEM NO: 8292

MACCRECOR.SIDE ROLLING TYPE.1022049

HOSE, BSP, ASSY TYPE: K102176 DIMENSIONS ( 4 X 08 X 08 L=1400); ITEM NO:8037

MACCRECOR.SIDE ROLLING TYPE.1099784

HOSE, BSP, ASSY TYPE: K102176 DIMENSIONS ( 4 X 08 X 12 L=1300; ITEM NO: 8033

MACCRECOR.SIDE ROLLING TYPE.1099794

HOSE, BSP, ASSY TYPE: K102176 DIMENSIONS ( 6 X 12 X 12 L=1300); ITEM NO: 8032

MACCRECOR.SIDE ROLLING TYPE.1099814

HOSE, BSP, ASSY TYPE: K102176 DIMENSIONS ( 4 X 08 X 08 L=1300); ITEM NO: 8031

MACCRECOR.SIDE ROLLING TYPE.1099783

HOSE, BSP, ASSY TYPE: K102176 DIMENSIONS ( 4 X 08 X 12 L=1400); ITEM NO: 8030

MACCRECOR.SIDE ROLLING TYPE.1099795

HOSE, BSP, ASSY TYPE: K102176 DIMENSIONS ( 4 X 08 X 12 L=600); ITEM NO: 8035

MACCRECOR.SIDE ROLLING TYPE.1099787

VHOSE, BSP, ASSY TYPE: K102178 DIMENSIONS ( 4 X 08 X 08 L=800); ITEM NO: 8034

MACCRECOR.SIDE ROLLING TYPE.1099976

HOSE, BSP, ASSY TYPE: K102180 DIMENSIONS ( 4 X 08 X 08 L=800); ITEM NO: 8036

MACCRECOR.SIDE ROLLING TYPE.1100020
