"Type/ Model:-BXM-AL-35-2200

MAKER : KOREA PHE CORPORATION" "TUBE STACK COMPLETE

ATMOSPHERIC CONDENSOR

Type/ Model:-BXM-AL-35-2200

MAKER : KOREA PHE CORPORATION

NAMEPLATE DETAILS

Shell & tube type,Hot side fluid:- Steam, Cold side fluid:- SW.

FLOWRATE  - 27.911 KG/HR  /  140 M3/HR

TEMP IN/OUT - 662 Kcal/kg 80 deg c / 32-40.3 deg C

Heat Exchanged - 356.403 Kcal/hr

Heat transfer area - 31.8 m2

Design pressure:- 8 / 4.0 bar

Test pressure -     12 / 6 bar

Weight -      568 / 790 kg

Serial No. KPME 1650007 - 2016.06

NO. OF TUBES - 150

TUBE DIMENSIONS - 16 mm DIA x 2200 LENGTH x 1.0 mm t

" KOREA PHE CORPORATION.BXM-AL-35-2200.NA
