063007G-81-DD
"MAKER:HYUNDAI
TYPE:6S60MC-C" "EXHAUST GAS AFTER CYLLINDER
SYMBOL: TEA-427
RANGE: 0-600 DEG.C
TYPE: NiNc-NiAl
L=250 mm
Screw= PF 3/4"
"MAKER:HYUNDAI
TYPE:6S60MC-C" "MAIN L.O LOW PRESS (SHUT DOWN) PRESSURE SWITCH
SYMBOL: PS-SHD335
TYPE: 9B0.2076.750
RANGE: 0-4 KG/Cmm2"
"MAKER:HYUNDAI
TYPE:6S60MC-C" "CONTROL AIR FWE PRESSURE SWITCH
SYMBOL: PSA-409
TYPE: 9B0.2077.751
RANGE: 0-6 KG/Cmm2"
"MAKER:HYUNDAI
TYPE:6S60MC-C" "AUX. BLOWER AUTO START/STOP PRESSURE SWITCH
SYMBOL: PSC-418
TYPE: 941.2375
RANGE: 0.2-1.6 KG/Cmm2"
"MAKER:HYUNDAI
TYPE:6S60MC-C" "MAIN L.O INLET PRESSURE TRANSMITTER
SYMBOL: PEA-331
PE-SLD330
TYPE: 8244.76.2310.01.11
RANGE: 0-4 KG/Cm2"
"MAKER:HYUNDAI
TYPE:6S60MC-C" "JACKET C.F.W INLET PRESSURE TRANSMITTER
SYMBOL: PEA-383
PE-SLD384
TYPE: 8244.77.2310.01.11
RANGE: 0-6 KG/Cm2"
"MAKER:HYUNDAI
TYPE:6S60MC-C" "F.O INLET PRESSURE TRANSMITTER
SYMBOL: PEA-306
TYPE: 8244.79.2310.01.11
RANGE: 0-16 KG/Cm2"
"MAKER:HYUNDAI
TYPE:6S60MC-C" "L.O INLET TEMPERTURE SENSOR
SYMBOL: TEA-312
TYPE: PT-100
RANGE: 0-200 DEG.C
L=120 mm
D=12.7 mm
Screw= PF 3/4"
"MAKER:HYUNDAI
TYPE:6S60MC-C" "PISTON COOLING OIL OUTLET TEMPERTURE SENSOR
SYMBOL: TEA-318
TYPE: PT-100
RANGE: 0-200 DEG.C
L=120 mm
D=12.7 mm
Screw= PF 3/4"
"MAKER:HYUNDAI
TYPE:6S60MC-C" "THRUST BEARING SEGMENT TEMPERTURE SENSOR
SYMBOL: TEA-350
TYPE: PT-100
RANGE: 0-200 DEG.C
L=130 mm
D=10 mm
Screw= PF 3/4"
"MAKER:HYUNDAI
TYPE:6S60MC-C" "JACKET COOLING WATER OUTLET TEMPERTURE SENSOR
SYMBOL: TEA-388
TYPE: PT-100
RANGE: 0-200 DEG.C
L=80 mm
D=12.7 mm
Screw= PF 3/4"
"MAKER:HYUNDAI
TYPE:6S60MC-C" "SCAVENGE AIR FIRE ALARM TEMPERTURE SENSOR
SYMBOL: TEA-388
TYPE: PT-100
RANGE: 0-200 DEG.C
L=200 mm
D=12.7 mm
Screw= PF 3/4"
"MAKER:HYUNDAI
TYPE:6S60MC-C" "F.O INLET TEMPERTURE SENSOR
SYMBOL: TEA-388
TYPE: PT-100
RANGE: 0-200 DEG.C
L=100 mm
D=12.7 mm
Screw= PF 3/4"
"MAKER:HYUNDAI
TYPE:6S60MC-C" "THERMOCOUPLE AMPLIFIER
MAKER: DAEYANG INSTRUMENT CO.LTD
RANGE: 0-600 DEG.C
MODEL: JK-2T-60T
MAX. LOAD IMPEDENCE: 250 OHMS
SOURCE: DC 24V
CIRCUIT CURRENT: 4 – 20 mA"
