"System: VISCOMETER LR1 CARRIER [VCMTRCAR]

Particulars : MAKER :ALFA LAVAL

BOOK NO: 1810723-02

PRODUCT NO.: 1010021-01,1010022-01" VISCOSITY SENSOR ALFA LAVAL.NA.176719401

"System: VISCOMETER-SPRUCE 2 [VSCMTR]

Particulars : MAKER: ALFA LAVAL

Subsystem: VISCOCITY CONTROL UNIT [VCU]

902499580

EVT20 UPGRADE KIT

Maker : ALFA LAVAL EUROPE" "AE VISCO INTERFACE BOARD

PART NO: 1767194-02:

SUPPLY VOLTAGE : 17V AC, 50/60HZ

POWER CONSUMPTION : 17 TO 25 Watt

VISCOSITY : 4 - 20 Ma max load 400 Ohm

TEMP : 4 - 20 Ma max load 400 Ohm" ALFA LAVAL.NA.02

"System: VISCOMETER-SPRUCE 2 [VSCMTR]

Particulars : MAKER: ALFA LAVAL

Subsystem: VISCOCITY CONTROL UNIT [VCU]

902499580

EVT20 UPGRADE KIT

Maker : ALFA LAVAL EUROPE" "VISCOSITY SENSOR

VISCOSITY RANGE : 0-50mPA

TEMP. RANGE : 0 - 200 Deg

TEMP. TRANSMITTER : PT100

FUEL TEMP: 180 Deg

MATERIAL SENSOR:STAINLESS STEEL 316

CONNECTION : .MALE THREAD M40 x 1.5

SIGNAL CABLE LENGTH : 5 MTR" ALFA LAVAL.NA.1767194-01
