"Equipment: / OIL HYDR.OPERATED BUTTERFLY VALVE

Manufacturer : NAKAKITA SEISAKUSHO CO LTD

Type: NS  PIBT-3200 SERIES

Book No. : F-35  - REMOTE CONTROL EQUIPMENT OF BILGE &BALLAST PIPE LINE

Drawing No. :  PBT3-E8331 / BT4-B4351" "BUTTERFLY VALVE COMPLETE /NOMIMAL SIZE:200mm / d1:200mm / L: 80mm / L1:1.5mm / H:350mm / H1:199mm / H2 :284mm /11:195mm / 12:195mm / 13: 35mm / 14:93mm /15:72,5mm /17: 96mm / FOR ACTUATOR TYPE  :PACBOU-O1P

PAGE: 7" NAKAKITA SEISAKUSHO CO.,LTD.PIBT-3200
