Maker: SPERRE

COMPRESSION RING 3509 3 0 0

SPERRE.HV1/120.3509

2 COMPRESSION RING 3508 3 0 0

SPERRE.HV1/120.3508

3 OIL SCRAPPER RING 3490 3 0 0

SPERRE.HV1/120.3490

4 PRESSURE GAUGE, LP 3771 2 0 0

SPERRE.HV1/120.3771

5 SAFETY VALVE, HP 4422 2 0 0

SPERRE.HV1/120.4422

6 PRESSURE GAUGE, HP 3773 2 0 0

SPERRE.HV1/120.3773

7 SAFETY VALVE, LP 4424 2 0 0

SPERRE.HV1/120.4424

8 DELIVERY VALVE, HP COMPLETE 3004 3 0 0

SPERRE.HV1/120.3004

9 COPPER WASHER, HP VALVE 3902 3 0 0

SPERRE.HV1/120.3902

11 SUCTION VALVE, HP COMPLETE 3003 3 0 0

SPERRE.HV1/120.3003

12 GASKET, FIXTURE BRACKET 4128 3 0 0

SPERRE.HV1/120.4128

13 CLAMPING PIECE, HP VALVE 1454 3 0 0

SPERRE.HV1/120.1454

14 VALVE UNLOADER, COMPLETE 3245 2 0 0

SPERRE.HV1/120.3245

15 COPPER WASHER 3929 3 0 0

SPERRE.HV1/120.3929

UNLOADER PISTON 3316 3 0 0

SPERRE.HV1/120.3316

17 UNLOADER COVER 3302 2 0 0

SPERRE.HV1/120.3302

18 GASKET, LP VALVE COVER 4012 3 0 0

SPERRE.HV1/120.4012

19 CLAMPING PLATE, SUCTION VALVE 1493 3 0 0

SPERRE.HV1/120.1493

20 SUCTION VALVE, LP COMPLETE 3007 3 0 0

SPERRE.HV1/120.3007

21 COPPER WASHER, LP VALVE 3903 3 0 0

SPERRE.HV1/120.3903

22 COPPER WASHER 3928 3 0 0

SPERRE.HV1/120.3928

23 CLAMPING SCREW 3735 3 0 0

SPERRE.HV1/120.3735

25 CLAMPING PLATE, DELIVERY VALVE 1494 3 0 0

SPERRE.HV1/120.1494

26 DELIVERY VALVE, LP COMPLETE 3008 3 0 0

SPERRE.HV1/120.3008

28 GRIPPER LOCKING PIN 3230 3 0 0

SPERRE.HV1/120.3230

29 GRIPPER, LP SUCTION VALVE 3287 3 0 0

SPERRE.HV1/120.3287

30 GRIPPER SPRING, LP SUCTION 3095 3 0 0

SPERRE.HV1/120.3095

31 VALVE NUT 3241 3 0 0

SPERRE.HV1/120.3241

32 VALVE SEAT, HP SUCTION 3057 3 0 0

SPERRE.HV1/120.3057

33 FIXING PIN 3140 3 0 0

SPERRE.HV1/120.3140

34 VALVE PLATE, LP VALVE 3104 3 0 0

SPERRE.HV1/120.3104

35 VALVE SPRING, LP SUCTION 3257 3 0 0

SPERRE.HV1/120.3257

36 VALVE SPACER RING 3180 3 0 0

SPERRE.HV1/120.3180

37 VALVE CATCHER, LP SUCTION 3157 3 0 0

SPERRE.HV1/120.3157

38 VALVE BOLT, LP SUCTION 3204 3 0 0

SPERRE.HV1/120.3204

39 VALVE NUT 3235 3 0 0

SPERRE.HV1/120.3235

40 VALVE WASHER, HP SUCTION 3132 3 0 0

SPERRE.HV1/120.3132

41 VALVE CATCHER, HP SUCTION 3153 3 0 0

SPERRE.HV1/120.3153

45 VALVE BOLT, LP VALVE 3201 3 0 0

SPERRE.HV1/120.3201

47VALVE CATCHER, LP DELIVERY 3058 3 0 0

SPERRE.HV1/120.3058

48VALVE NUT 3236 3 0 0

SPERRE.HV1/120.3236

49 VALVE WASHER, LP VALVE 3131 3 0 0

SPERRE.HV1/120.3131

Type: HV1/120
