MAKER:KAWASAKI –MAN B&W

TYPE: NA48/SO1073

MACHINE NO.: 0840

SAFETY RELIEF VALVE COMPLETE FOR CYLINDER COVER

KAWASAKI MAN B&W.NA48/SO1073.001/911-1

M/E TURBOCHARGER

KAWASAKI HEAVY INDUSTRIES LTD.

KAWASAKI –MAN B&W EXHAUST GAS T/C

TYPE: NA48/SO1073

MACHINE NO.: 0840

Max. Design Speed: 17800r/min

Max. Service Speed: 16800r/min

Max. Gas Temp.: 620oC

Number: 04B193T  310AN66

Nozzle Area: 380.0cm2 , Diffuser Area: 289.5cm2 x 18deg

KAWASAKI MAN B&W.NA48/SO1073.NA

NOZULE RING

KAWASAKI MAN B&W.NA48/SO1073.PART NO: 513.001

LOCATING BEARING

KAWASAKI MAN B&W.NA48/SO1073.PART NO: 517.075,

BEARING BUSH

KAWASAKI MAN B&W.NA48/SO1073.PART NO: 517.161,

THRUST RING

KAWASAKI MAN B&W.NA48/SO1073.PART NO: 520.028,

LOCATING RING

KAWASAKI MAN B&W.NA48/SO1073.PART NO: 520.035,

CYLINDER LINER

KAWASAKI MAN B&W.NA48/SO1073.101/903-2

CYLINDER LINER COOLING JACKET

KAWASAKI MAN B&W.NA48/SO1073.2
