FOR:Machinery Name: FEED PUMP IMPELLER SHAFT

MITSUI ENGINEERING.SVQ50.17

IMPELLER KEY

MITSUI ENGINEERING.SVQ50.18

COUPLING KEY

MITSUI ENGINEERING.SVQ50.19-1

IMPELLER NUT

MITSUI ENGINEERING.SVQ50.19-2

SLEEVE

MITSUI ENGINEERING.SVQ50.20

INTERMEDIATE SLEEVE

MITSUI ENGINEERING.SVQ50.27

PACKING

MITSUI ENGINEERING.SVQ50.22

MOUTH RING( Outer Dia – 104.6)

MITSUI ENGINEERING.SVQ50.24

MOUTH RING( Outer Dia – 105.6)

MITSUI ENGINEERING.SVQ50.31

CASING RING

MITSUI ENGINEERING.SVQ50.38A

MITSUI ENGINEERING.SVQ50.38B

MITSUI ENGINEERING.SVQ50.39

Machinery Model/Type:  SVQ50

Serial No:            1027071

Specification:      2.5  M3/H, TOTAL HEAD : 100 M, SUCTION HEAD :NPSH 5M, HYDRAULIC TEST :1.8 MPaG,

HULL NO. 1708/09/10, PUMPING LIQUID : FEED WATER, LIQUID TEMP. 80 0C, REQ. NPSH : 0.6 M

FLANGES(SUC.X DIS.): JIS 5K X 16K.

MITSUI ENGINEERING & SHIPBUILDING CO., LTD

IMPELLER

MITSUI ENGINEERING.SVQ50.16
